SLM FLORE

MULKTI-PURPOSE SHALLOW DRAFT ICE CLASS TUG

Name: SLM FLORE
Type: Multi Purpose shallow draft ice class tug
Classification: BV I HULL MACH Tug Unrestricted navigation AUT-UMS, ICE CLASS 1B
Flag: United Kingdom
Year of built: 2007
Place of built: IHC Shipyards, The Netherlands

SLM Flore – data sheet

Contact

Specification SLM FLORE

Main Dimensions

Length, m: 30.05
Beam,m: 10.00
Clear deck area, m2: 105
GRT / NRT: 294 / 88
Draft max, m: 2.81
Minimum Operating draft at 7 days, endurance, m: 2.40

Performance

Bollard pull, t: 35.0
Speed, kn: 10,0
Endurance, days: 15

Machineries / Propulsion

Main Engines: 2 x CAT 3512B
Total Power: 2 x 939 kW
Propulsion units: 2 x FPP in Kort nozzle
Bow thruster: 200 kW
Generator sets: 1 x Cat C9, 1 x CAT 3056
Fifi pump engine: CAT 3406C

Deck Equipment

Deck crane: 9.25 t @ 12.19 m
Towing winch: 50 t
Towing wire rope, length x diameter: 700 m x 38 mm
Stem roller: SWL 100 t
Anchor handling wire rope, lenght x diameter: 210 m x 44 mm
Towing pins: SWL 40 t
Anchor handling wire stopper: 30 t

Tanks Capacities

Fuel oil, m3: 91.30
Freshwater, m3: 24.80
Sewage water, m3: 12.39

Navigation / Communication Equipment

Navigation / Communication Equipment: GMDSS A1 + A2 + A3

Accomodation

Single bed: 2 cabins
Two bed: 2 cabins
Four bed: 1 cabin
Total: 10 persons

SLM FLORE data sheet
